SCHOOL DESIGN PLAN
A Hostel and School designed in 130’ X 230’ size rectangular plot.
North side main road abutting the plot.
Front side in plot , we have planned school building and in back side we have planned Hostel building.
In school building on ground floor we have planned fees record room, staff room, waiting area, director room, Principal cabin, 5 class rooms, girl’s toilet and boy’s toilet.
On first floor we have planned 6 class rooms ,computer lab, library and lab.
For access all floor we have planned staircase and lift for handicrafts students.
Second and third floor is typical floors planning.
On this floor we have planned 9 classrooms.
On terrace floor we have designed stair cabin and other space for open terrace.
Hostel building is G + 3 floors.
On ground floor we have planned reception, waiting area, store room, warden room, common kitchen, and dinning hall.
On first floor we have planned 3 Hall , with att bath and toilet.
In 2 Hall-12 beds in each hall and in 1 hall- 16 beds.
On terrace floor we have designed stair cabin and other space use for activities.
